7.3L Super Duty Truck Engine

The ALL-NEW 7.3L V8 Ford gasoline crate engine from the 2020 F250 Super Duty features:

• 7.3L displacement
• Bore 107.2 mm x stroke 101.0 mm
• Cast iron block
• Aluminum cylinder heads
• Intake valve diameter 55.13 mm
• Exhaust valve diameter 42.53 mm
• Lift (intake/exhaust) 13.67 mm / 15.26 mm
• Cam-in-block OHV design w/variable cam timing
• Forged steel crankshaft
• Cast Aluminum pistons
• 430 HP at 5,500 rpm
• 475 lb/ft of torque at 4,000 rpm
• 10.5:1 compression
• Port fuel injection
• Firing order: 1-5-4-8-6-3-7-2

The engine assembly includes:

• Composite Intake manifold and 80 mm throttle body
• Left and Right exhaust manifolds
• 8 quart aluminum oil pan/cooler
• Ignition coils and wires
• Production flex plate
• M-6038-73 shipping and storage cradle
• Factory lift brackets
• Bellhousing bolt pattern same as 4.6/5.4 and 5.0 Coyote
• Engine weight: 580 lbs.

For a 7.3L starter see M-11000-SD73

For FEAD kit see M-8600-SD73

For A/C add-on kit see M-8600-SD73AC

For control pack see M-6017-73A

For low profile intake see M-9424-73LP
